ATMEGA8L 8A 8PU DIP 28 Pin Microcontroller MCU AVR IC in Pakistan


High-performance, Low-power AVR 8-bit
Nonvolatile Program and Data Memories
Peripheral Features
Special Microcontroller Features



High-performance, Low-power AVR 8-bit
– 130 Instructions – Most Single Clock Cycle Execution
– 32 x 8 General Purpose Working Registers
– Up to 6 MIPS Throughput at 16MHz
– Fully Static Operation
– On-chip 2-cycle Multiplier
Nonvolatile Program and Data Memories
– 8k Bytes of In-System Self-Programmable Flash
– Optional Boot Code Section with Independent Lock Bits
– 512 Bytes EEPROM
– Programming Lock for Software Security
– 1K Byte Internal SRAM
Peripheral Features
– On-chip Analog Comparator
– Programmable Watchdog Timer with Seperate On-chip Oscillator
– Master/Slave SPI Serial Interface
– Two 8-bit Timer/Counters with Separate Prescalar, Compare
– One 16-bit TImer/Counter with Seperate Prescaler, Compare and Capture mode
– Real TIme Counter with Separate Oscillator
– Three PWM Channels
– 6-channel ADC
– Byte-oriented Two-wire Serial Interface
– Programmable Serial USART
Special Microcontroller Features
– Power-on Reset and Programmable Brown-out Detection
– Internal Calibrated RC Oscillator
– External and Internal Interrupt Sources
– Five Sleep Modes: Idle, ADCNoise Reduction, Power-save, Power-down and Standby
I/O and Packages
– 23 Programmable I/O Lines
– 28-lead PDIP, 32-lead TQFP, 32-pad MLF
Operating Voltages
– 4.5-5.5V for ATmega8L
Speed Grades
– 0-16 MHz for ATmega8L
Power Consumption
– Active: 3.6mA
– Idle Mode: 10mA
– Power-down Mode: 0.5 µA
