Fingerprint processing includes two parts: fingerprint enrollment and fingerprint matching (the matching can be 1:1 or 1:N).When enrolling, user needs to enter the finger two times. The system will process the two time finger images, generate a template of the finger based on processing results and store the template.
Features
Fingerprint sensor type: Optical
Sensor Life: 100 million times
Static indicators: 15 KV
Interface: UART(TTL logical level)
RS232 communication baud rate: 4800 BPS-115200 BPS
Dimension: 55X32X21.5 mm
Image Capture Surface: 15:18 mm
Verification Speed: 0.3 sec
Scanning Speed: 0.5 sec
Character file Sizes: 256 bytes
Template Size: 512 bytes
Capacity: 512
Security level: 5-1,2,3,4,5 highest
False Acceptance Rate (FAR): 0.0001%
False Rejection Rate (FRR): 0.1%
Resolution: 500 DPI
Voltage: 3.6-6.0 VDC
Working current: Typical 90 mA, Peak 150 mA
Matching Method: 1:1 & 1:N
Resolution: 500 DPI
