6 Volt DC Gear Motor Price in Pakistan

(3 customer reviews)

600

  • High-Power DC Gearmotor
  • Nominal Voltage: 6V
  • No Load RPM: 97
  • Stall Current: 6.5A
  • Stall Torque: 210 oz-in
  • Shaft Diameter: 4 mm



Purchase this product now and earn 600 Points!

Description

6 Volt DC Gear Motor Price in Pakistan
6V 97RPM Metal Gearmotor
uses a brushed DC motor with extra strong magnets and a 99:1 metal gearbox to deliver a lot of power in a relatively small package. These units have a 0.315” long, 4 mm diameter D-shaped output shaft. These motors are intended for use at 6 V. In general, these kinds of motors can run at voltages above and below this nominal voltage, so they should comfortably operate in the 3 – 9 V range, though they can begin rotating at voltages as low as 1 V. Higher voltages could start negatively affecting the life of the motor.

Specifications

  • Gear Ratio: 98.78:1
  • Nominal Voltage: 6V
  • No Load RPM: 97
  • No Load Current: 0.55A
  • Rated RPM: 65
  • Rated Torque: 47 oz-in
  • Stall Current: 6.5A
  • Stall Torque: 210 oz-in
  • Shaft Type: D-Shaped
