Sanwa – CD800A – Battery Powered Digital Multimeter

Brand name Sanwa Electric Instrument Co.
Manufacturer Series Number CD800A3288
Part number CD800A3288
Number of items 1
Product weight 200 grams
Model number CD800a

Battery : 2 AA batteries
Manufacturer : Sanwa Electric Instrument Co.
ASIN : B002P8M1KC
Item Model Number : CD800a

[Products]
The case is easy to carry and store.
The case comes with a protective cover that doubles as a stand.
Flame retardant material is used for the case and circuit board. CE standard product.
Safety standard: IEC61010-1 CAT. 600V compliant.

DC voltage
Measuring range 400m/4/40/400/600V
Maximum accuracy ±(0.7%+3)
Resolution 0.1mV
Input resistance 10M to 100MΩ
AC voltage
Measuring range 4/40/400/600V
Maximum accuracy ±(1.6%+5)
Resolution 0.001V
Input resistance 10M to 11MΩ
DC current
Measuring range 40m/400mA
Maximum accuracy ±(2.2%+5)
Resolution 0.01mA

AC current
Measuring range 40m/400mA
Maximum accuracy ±(2.8%+5)
Resolution 0.01mA
Resistance
Measurement range 400/4k/40k/400k/4M/40MΩ
Maximum accuracy ±(1.2%+5)
Resolution 0.1Ω
Capacitance
Measurement range 50n/500n/5μ/50μ/100μF
Maximum accuracy ±(5%+10)
Resolution 0.01nF
Frequency Range
Measurement range 5Hz to 100kHz
Maximum accuracy ±(0.5%+3)

Duty Ratio
Measurement range 20% to 80
Maximum accuracy ±(0.5%+5)
Continuity Buzzer sound at 10Ω to 120Ω or less Open circuit voltage: Approx. 0.4V
Diode test Open circuit voltage: Approx. 1.5V
Display: Numeric section 4000
Sample rate Numeric section: 3 times/sec.
Frequency characteristics 40Hz to 400Hz
Fuse 0.5A/250V Φ5×20mm Ceramic
Power supply R6P (AA dry cell) 1.5Vx2
Battery life: Approx. 500 hours at DCV (manganese batteries)
Dimensions/Mass H176 x W104 x D46mm / Approx. 340g
Test lead length / pin tip Total length approx. 0.7m / 19mm
