UNI-T UT612 LCR meter is a more advanced meter used to measure inductance, capacitance and resistance. Advanced features include series/parallel measurement modes, quality factor/loss/phase angle measurements, equivalent/DC resistance measurements and 5 kinds of measurement frequency in AC mode for selection. UT612 can be easily operated in production lines, component inspection and electronic maintenance.
Specifications |
Range |
Best Accuracy |
| Model | UT612 | |
| Inductance (H) | 20uH～2000H | ±(0.5%+5) |
| Capacitance (F) | 200pF～20mF | ±(0.5%+5) |
| Resistance (Ω) | 20Ω～200MΩ | ±(0.3%+5) |
| Test Frequency (Hz) | 100Hz/120Hz/1kHz/10kHz/100kHz | √ |
| Operational Voltage | 0.6Vrms | √ |
| Test Parameters | L/C/R/DCR/Q/D/θ/ESR | √ |
Features |
||
| Display Count | 20000 | |
| D/Q Display Count | 2000 | |
| D/Q Resolution | 0.001 | √ |
| Auto Range | √ | |
| Real-Time Display Test Frequency | √ | |
| Measurement Mode | Series/Parallel | √ |
| Auto Power Off | √ | |
| Low Battery Indication | ≤6.8V | √ |
| Data Hold | √ | |
| Relative Mode | √ | |
| USB Interface | √ | |
| USB Interface/PC Data Records | 60000 | |
| LCD Backlight | √ | |
| Analog Bar Graph | 26 | |
| Deviation Ratio Measurement | √ | |
| Comparsion Function | √ | |
| Calibration Function | √ | |
| Output Impedance | 120Ω | √ |
| Auto LCR Smart Check and Measurement | √ | |
Device Characteristics |
||
| Power | 9V Battery (6F22) or USB | |
| LCD Size | 40mm X 63mm | |
| Product Colour | Red and Grey | |
| Product Net Weight | 374g | |
| Product Size | 96mm X 193mm X 47mm | |
| Standard Accessories | Battery, SMD Test Clamp, USB Interface Cable, Multi-Purpose Socket, PC Software CD | |
| Standard Individual Packing | Gift Box, English Manual | |
| Standard Quantity Per Carton | 24pcs | |
| Standard Carton Measurement | 610mm X 450mm X 355mm (0.097 CBM Per Standard Carton) | |
| Standard Carton Gross Weight | 22.3kg | |
