4S 20A BMS Li-ion Battery Protection Board Charging Module

  • Model Number:18650 Li-ion Lithium Battery BMS 4S
  • Shortage delay: 100 – 600S
  • Shortage protect recover: YES
  • Charging current: 20A
  • discharging current: 20A
  • Charging voltage: 16.8V for 4S
  • Operating Temperature: -40 to 80

400.00

Description

  • Li-ion Lithium Battery BMS lithium battery charging module
  • BMS Type: Drive IC
  • Model Number:18650 Li-ion Lithium Battery BMS 4S
  • Package: 1pcs 25A 3S Protection Board
  • 100% Brand new and high quality 18650
  • Module for Li-POLYMER LiMnO Protect Parameter (3.6V/3.7V)
  • Single Cell overcharge protect voltage: 4.23 – 4.28V
  • Single Cell overcharge protect recover voltage: 4.08 – 4.18
  • Overcharge protect delay: 0.5 – 1.5S
  • Single Cell over-discharge protect voltage: 2.72 – 2.88V
  • Single Cell over-discharge protect recover voltage: 2.9 – 3.1V
  • Overcharge protect current: 60A
  • Over-discharge protect current: 60A
  • Over-discharge protect delay: 0.5 – 1.5S
  • Temperature protect: YES
  • Disconnect protect: YES
  • Shortage protect: YES
  • Shortage delay: 100 – 600S
  • Shortage protect recover: YES
  • Charging current: 20A
  • discharging current: 20A
  • Charging voltage: 16.8V for 4S
  • Operating Temperature: -40 to 80
1x 4S 20A BMS Li-ion Battery Protection Board Charging Module
