2S 3A 5A Li-ion Lithium Battery 18650 Charger BMS Protection Board Module

  • Number of Cells: 2
  • Working Current: 3A
  • Instantaneous Peak Current: 5A
  • Over Charge Voltage Range: 4.25-4.35V ± 0.05V
  • Over Discharge Voltage Range: 2.5-3.0V ± 0.05V

70.00

Description

Specification :

  • Number of Cells: 2
  • Working Current: 3A
  • Instantaneous Peak Current: 5A
  • Over Charge Voltage Range: 4.25-4.35V ± 0.05V
  • Over Discharge Voltage Range: 2.5-3.0V ± 0.05V
  • B+ B-: The interface of battery core
  • P+ P-: The connector of the battery board
  • MB: The connection point between the batteries
  • B+: Battery V+ Positive
  • B-: Battery V- Negative
  • P+: Output / Charging V+
  • P-: Output / Charging V-
  • Size: Approx. 36 x 6 x 1 mm(LxWxH).
  • Over-Discharge Detection Voltage: 2.3-3.0V±0.05V
  • 2S 3A Li-ion Lithium Battery 7.4V 8.4V 18650 Charger Protection Board Module is a small mountedLi-ion Lithium Battery charger protection module. This small and smart battery charger protection module comes with the various features likeShort circuit protection,Overcharge protection, Over-discharge protection, Overcurrent protection. It is very easy to install and convenient to use in all your DIY portable projects.
