ACS712 Range Current Sensor Module of 5A, 20A, 30A in Pakistan

This Sensor is available in 5A, 20A, 30A Range



  • its size is 31 x 13 x 14 mm.
  • its weight is 3g.
  • 4.5V to 5.5V DC are supply voltages.
  • the output voltage is VCC/2.

250.00270.00

  • 30A
  • 20A
  • 5A
Clear

Description

5A, 20A, 30A Range Current Sensor Module ACS712 in Pakistan





ACS712 range current sensor module is consists of 5, 20,30 amps. this sensor is also called the Hall sensor device. because it is precise and low- cost. this module contains a linear Hall circuit with copper conduction. this copper conduction path near the surface of the die. this module contains copper conduction path which generates a magnetic field. then this Hall IC converts into a proportional voltage. the basic and important requirement of the applications is over-current protection circuits and controlling the current flow. there are many other basic and important applications which are over-current protection circuits, battery chargers, switching mode power supplies, digital watt meters, and programmable current sources. Get all types of sensors, modules, and Copters at Pakistan’s Best online Store which is epro.pk.



this range current sensor based on the ACS712 sensor. this ACS712 detects AC or DC current accurately. there are 3 different ranges of the current sensor and these are 5A, 25A, and 30A. this accurate current sensor can measure current according to its ranges. these current signals can be read via analog I/O port for Arduino. ACS712 is fully integrated. this sensor is also called a hall-effect based linear current sensor module. this sensor also contains 2.1kV RMS isolation, this module also contains a low-resistance current conductor.





5A Range Current Sensor Module ACS712 in Pakistan



Specifications of 5A Range Current Sensor Module ACS712:







  • 66 mV/A is its output voltages.
  • 4.5 to 5.5 volts are its operating voltage range.
  • 31 x 14mm is its size.
  • 80kHz is its bandwidth size.
  • 1.5% is its output error at 25 degrees centigrade.
  • 11.2m ohms is its internal conductor resistance.
  • 2.1 kV RMS is its minimum isolation voltages from 1- 4 pins to 5- 8 pins.
  • 66 to 185 mV/A is its output sensitivity.



Features of 5A Range Current Sensor:







  •  this current module measures positive and negative 5 amps.
  • this current module operated on a single supply of 5V.
  • its output voltages proportional to AC or DC currents.
  • this module contains an on-board power indicator.
  • it has nearly zero magnetic hystereses.
  • this sensor contains factory-trimmed for accuracy.
  • this module has an extremely stable output offset voltage.





20A Range Current Sensor Module ACS712 in Pakistan



Specifications of 20A Range Current Sensor Module ACS712:







  • 31 x 13 x 14 mm is module size.
  • 3g is the sensor’s weight.
  • supply voltages are 4.5 to 5.5V DC.
  • -20 to 20 amp is its measuring current range.
  • 100mV/A is its sensitivty.
  • this sensor contains ACS712_ ELC-20A chip.
  • 5V is its power supply voltages. this sensor also has an onboard power indicator.
  • VCC/2 is its output voltages.
  • +- 20 amps is current range of this sensor.
  • the analog output value is 185mV/A.



30A Range Current Sensor Module ACS712 in Pakistan





Specifications of 30A Range Current Sensor Module ACS712 :







  • 31 x 13 x14 mm is the sensor’s size.
  • 30g is the weight of 30A current sensor.
  • its supply voltages are 4.5 to 5.5 volts.
  • -30 to 30 amp is its measuring current range.
  • 66 mV /A is its sensitivity value.
  • ACS712 chip is used in this sensor.
  • it also contains an onboard power indicator. 5V is its power supply value.
  • this module can measure -30 to 30 amps.
  • 185mV/A is its corresponding analog output.
  • VCC/2 is its output voltages.



Package Included:



  • One Piece of ACS712 Range Current Sensor Module / Hall Sensor.
